Basic parameters (according to customized requirements specifications)
·Maximum weighing capacity: 300kg
·Minimum inductance: 0.01kg
·Filling range: 10-300kg
·Filling error: ≤0.1%
·Tip material: SUS304 stainless steel (tetrafluoroethylene)
·Applicable container: ≤Ф600xh1000mm
·Explosion-proof grade: EXdiaIIBT4
·Power supply: AC220/50Hz
·Using air source: 0.4-0.8Mpa
·Using temperature: -10℃-40℃
·Control mode: 3-speed pneumatic control
·Filling method: plug-in, below the liquid surface
·Material interface: DN40 quick-install pagoda joint, optional flange joint.

Features
·Real-time display of weighing value
·Built-in roller automatic brake
·200 groups of formulas can be set and stored
·Two filling methods of net weight/gross weight
·Automatic/manual two operation modes
·Each gun feeding fast/heavy/slow three-level speed
·Emergency stop/power off/tank removal triple protection
·Unique anti-drip device to prevent materials from dripping on the bucket;
·Easy operation: automatic delivery of empty barrels-manual single gun to barrel-start filling-filling completed-automatic gun lifting

Optional peripherals:
1. Pump
2. Filter
3. Conveyor
4. Backflow valve
5. Capping device
6. The automatic filling line can be designed according to the user's site

Optional models: standard type, explosion-proof type, all stainless steel structure type.
